Name: Festo 538273 Proximity sensor SIED-M12B-ZO-S-L
Brand: Festo

Proximity sensor SIED-M12B-ZO-S-L

The Festo 538273 is a round inductive industrial component featuring an EN 60947-5-2 compliant design with a 2 mm rated operating distance and 1.62 mm assured operating distance. This non-contact 2-wire sensor utilizes an N/C contact switching element function supporting a maximum DC switching frequency of 1200 Hz and an AC operating voltage range of 20 V to 265 V across an ambient temperature range of -25 °C to 85 °C. Certified with the RCM compliance mark and c UL us - Listed (OL) rating, it carries CE marking per the EU EMC and low voltage directives. Submit the exact part number, quantity, and application requirements to request a quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 538273
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 538273.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Design: Round
Conforms to standard: EN 60947-5-2
Certication: RCM compliance mark | c UL us - Listed (OL)
CE marking (see declaration of conformity): As per EU EMC directive | As per EU low voltage directive
Measuring principle: Inductive
Rated operating distance: 2 mm
Assured operating distance: 1.62 mm
Reduction factors: Aluminum = 0.5 | Stainless steel St 18/8 = 0.9 | Copper = 0.4 | Brass = 0.6 | Steel St 37 = 1.0
Ambient temperature: -25 °C...85 °C
Repetition accuracy: 0.1 mm
Switching output: Non-contact, 2-wire
Switching element function: N/C contact
Hysteresis: 0.02 mm...0.44 mm
Max. switching frequency DC: 1200 Hz
Max. switching frequency AC: 25 Hz
Max. output current: 200 mA
Voltage drop: 8 V
Minimum load current: 5 mA
Short-circuit protection: no
Operating voltage range AC: 20 V...265 V
DC operating voltage range: 20 V...320 V
Mains frequency: 50 Hz
Idle current: 1.5 mA
Reverse polarity protection: for all electrical connections
