Name: Festo 538277 Proximity sensor SIED-M18NB-ZO-S-L
Brand: Festo

Proximity sensor SIED-M18NB-ZO-S-L

The Festo part number 538277 is a round inductive industrial component featuring an 8 mm rated operating distance, a 6.5 mm assured operating distance, and an EN 60947-5-2 conformity design with RCM and c UL us - Listed certifications. Operating within an ambient temperature range of -25 °C to 85 °C, this 2-wire non-contact unit includes an N/C contact switching element function supporting a 20 V to 265 V AC operating voltage range, a maximum AC switching frequency of 25 Hz, and a maximum DC switching frequency of 340 Hz. It provides an output current up to 300 mA with a repetition accuracy of 0.2 mm and reduction factors specified at 1.0 for Steel St 37, 0.7 for Stainless steel St 18/8, 0.4 for Aluminum and Brass, and 0.3 for Copper. Submit the exact part number, quantity, and application requirements for a quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 538277
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 538277.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Design: Round
Conforms to standard: EN 60947-5-2
Certication: RCM compliance mark | c UL us - Listed (OL)
CE marking (see declaration of conformity): As per EU EMC directive | As per EU low voltage directive
Measuring principle: Inductive
Rated operating distance: 8 mm
Assured operating distance: 6.5 mm
Reduction factors: Aluminum = 0.4 | Stainless steel St 18/8 = 0.7 | Copper = 0.3 | Brass = 0.4 | Steel St 37 = 1.0
Ambient temperature: -25 °C...85 °C
Repetition accuracy: 0.2 mm
Switching output: Non-contact, 2-wire
Switching element function: N/C contact
Hysteresis: 0.03 mm...1.9 mm
Max. switching frequency DC: 340 Hz
Max. switching frequency AC: 25 Hz
Max. output current: 300 mA
Voltage drop: 8 V
Minimum load current: 5 mA
Short-circuit protection: no
Operating voltage range AC: 20 V...265 V
DC operating voltage range: 20 V...320 V
Mains frequency: 50 Hz
Idle current: 1.5 mA
Reverse polarity protection: for all electrical connections
