Festo
538286
Proximity sensor SIED-M30NB-ZO-K-L
The Festo part number 538286 is a round inductive industrial component featuring a rated operating distance of 15 mm, an assured operating distance of 12.15 mm, and conformity to standard EN 60947-5-2. It utilizes a non-contact 2-wire switching output with an N/C contact, accommodating an operating voltage range of 20 V to 265 V AC, a maximum AC switching frequency of 25 Hz, a maximum DC switching frequency of 220 Hz, and a maximum output current of 300 mA within an ambient temperature range of -25 °C to 85 °C. Certification includes the RCM compliance mark, c UL us - Listed (OL) status, and CE marking in accordance with EU EMC and low voltage directives. Submit the exact part number, quantity, and application requirements to receive a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 538286
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 538286.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Design
- Round
- Conforms to standard
- EN 60947-5-2
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU low voltage directive
- Measuring principle
- Inductive
- Rated operating distance
- 15 mm
- Assured operating distance
- 12.15 mm
- Reduction factors
- Aluminum = 0.5 | Stainless steel St 18/8 = 0.8 | Copper = 0.4 | Brass = 0.5 | Steel St 37 = 1.0
- Ambient temperature
- -25 °C...85 °C
- Repetition accuracy
- 0.4 mm
- Switching output
- Non-contact, 2-wire
- Switching element function
- N/C contact
- Hysteresis
- 0.04 mm...3.3 mm
- Max. switching frequency DC
- 220 Hz
- Max. switching frequency AC
- 25 Hz
- Max. output current
- 300 mA
- Voltage drop
- 8 V
- Minimum load current
- 5 mA
- Short-circuit protection
- no
- Operating voltage range AC
- 20 V...265 V
- DC operating voltage range
- 20 V...320 V
- Mains frequency
- 50 Hz
- Idle current
- 1.5 mA
- Reverse polarity protection
- for all electrical connections
- Electrical connection
- 2-wire | Cable
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 538286. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
