Name: Festo 542186 Branching module FRM-Y-D-MAXI
Brand: Festo

Branching module FRM-Y-D-MAXI

The Festo 542186 is a branching module featuring a die-cast aluminum housing with a product weight of 822 g and an any-position mounting design. This component operates within a pressure range of 0 MPa to 1.2 MPa (0 bar to 12 bar) and delivers a standard nominal flow rate of 20000 l/min in the main flow direction from 1 to 2, utilizing compressed air or inert gases compliant with ISO 8573-1:2010 [7:-:-]. It is constructed with G3/4 pneumatic connection 3, G1/4 pneumatic connection 4, RoHS-compliant materials, a moderate corrosion resistance class (CRC 2), and a DC operating voltage range of 0 V to 125 V while supporting media, ambient, and storage temperatures from -10 °C to 60 °C. Submit the exact part number, quantity, and application requirements to receive a formal quotation.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 542186
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 542186.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Mounting position: Any
Structural design: Branching module
Operating pressure: 0 MPa...1.2 MPa | 0 bar...12 bar
Standard nominal ow rate in main ow direction 1 -> 2: 20000 l/min
DC operating voltage range: 0 V...125 V
Operating medium: Compressed air as per ISO 8573-1:2010 [7:-:-] | Inert gases
Corrosion resistance class (CRC): 2 - Moderate corrosion stress
LABS (PWIS) conformity: VDMA24364-B1/B2-L
Storage temperature: -10 °C...60 °C
Air quality class at the output: Compressed air as per ISO 8573-1:2010 [7:-:-] | Inert gases
Temperature of medium: -10 °C...60 °C
Ambient temperature: -10 °C...60 °C
Product weight: 822 g
Pneumatic connection 3: G3/4
Pneumatic connection 4: G1/4
Note on materials: RoHS compliant
Housing material: Die-cast aluminum

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 542186. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
