Name: Festo 543416 Pneumatic interface VABA-S6-1-X1
Brand: Festo

Pneumatic interface VABA-S6-1-X1

The Festo part number 543416 is an industrial component featuring a Type 44 VTSA valve manifold interface with fieldbus electrical actuation via CPX, accommodating up to 16 double-solenoid valves or 32 single-solenoid valves. It offers 24 VDC nominal operating voltage, internal electronic fuse protection per pneumatic valve output, and comprehensive parameterization including per-channel failsafe, forcing, idle mode, and module monitoring. Housed in an IP65 and NEMA 4 rated enclosure with a product weight of 590 g, the unit operates in ambient temperatures from -5 °C to 50 °C and includes group diagnostics for pneumatic valve undervoltage alongside channel status LED indicators. Submit the exact part number, quantity, and application requirements to receive a formal quotation.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 543416
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 543416.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Valve manifold interface: Type 44, VTSA
Diagnostics: Undervoltage of pneumatic valves
Max. no. of valve positions: 16 for double-solenoid valves | 32 for single-solenoid valves
LED indicators: 1 group diagnostics | Channel status on pneumatic valves
Parameterization: Failsafe per channel | Forcing per channel | Idle mode per channel | Module monitoring
Fuse protection (short circuit): Internal electronic fuse per pneumatic valve output
DC operating voltage range: 21.6 V...26.4 V
Intrinsic current consumption at nominal operating voltage: Typ. 15 mA (electronics operating voltage supply) | Typ. 50 mA (pneumatic valve load power supply)
Max. power supply per channel: 0.2 A
Max. residual current per module: 4 A
Nominal operating voltage DC: 24 V
Electrical isolation between channel and internal bus: Yes, when using an additional supply for the pneumatic valves
Corrosion resistance class (CRC): 0 - No corrosion stress
LABS (PWIS) conformity: VDMA24364-B1/B2-L
Degree of protection: IP65 | NEMA 4
Ambient temperature: -5 °C...50 °C
Product weight: 590 g
Electrical actuation: Fieldbus
Electrical connection: Via CPX
Note on materials: RoHS compliant
Cover material: PA
Housing material: Die-cast aluminum

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 543416. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
