544218

Name: Festo 544218 Signal conditioner SVE4-IS-R-HM8-2P-M8
Brand: Festo

Signal conditioner SVE4-IS-R-HM8-2P-M8

The Festo 544218 industrial component features a 0 - 20 mA +/-0.6 mA signal range and dual PNP switching outputs with freely programmable switching functions and switchable elements. Operating on a 10 V...30 V DC voltage range, this part includes pulsed short-circuit protection and overload protection, functioning within an ambient temperature of -20 °C...70 °C and a UL-ambient temperature of -20 °C...60 °C. It is equipped with M8x1 A-coded 4-pin socket and plug connections conforming to EN 61076-2-104, holding RCM, c UL us - Listed (OL), CE, UKCA, and RoHS compliance certifications. Submit the exact part number, quantity, and application requirements for a quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 544218
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 544218.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Certication: RCM compliance mark | c UL us - Listed (OL)
UL-ambient temperature: -20 °C...60 °C
CE marking (see declaration of conformity): As per EU EMC directive | As per EU RoHS directive
UKCA marking (see declaration of conformity): To UK instructions for EMC | To UK RoHS instructions
Note on materials: RoHS compliant
Signal range: 0 - 20 mA +/-0.6 mA
Ambient temperature: -20 °C...70 °C
Switching output: 2xPNP
Switching function: Freely programmable
Switching element function: Switchable
Short-circuit protection: Pulsed
Overload protection: Available
DC operating voltage range: 10 V...30 V
Electrical connection 1, connection type: Socket
Electrical connection 1, connection technology: M8x1 A-coded as per EN 61076-2-104
Electrical connection 1, number of pins/wires: 4
Electrical connection 1, type of mounting: Screw-type lock | not rotatable | Compatible with rotatable screw-type lock
Electrical connection 2, connection type: Plug
Electrical connection 2, connection technology: M8x1 A-coded as per EN 61076-2-104
Electrical connection 2, number of pins/wires: 4
Electrical connection 2, type of mounting: Snap-locking | Screw-type lock | not rotatable | Compatible with snap-locking | Compatible with rotatable screw-type lock
Product weight: 19 g
Housing material: ABS
Setting options: Teach-in
Degree of protection: IP65

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 544218. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
