Festo
546157
Air solenoid valve VZWM-L-M22C-N34-F4
The Festo part number 546157 is a servo-controlled diaphragm valve featuring a soft sealing principle, a 27.5 mm nominal width, and a 2/2-way, closed, monostable valve function with non-reversible flow direction. Designed for in-line installation with a 3/4 NPT fitting connection and a preferred upright mounting position, this electrical component operates with compressed air as per ISO 8573-1:2010 [7:4:4], inert gas, water, and neutral liquids. It accommodates medium pressures from 0.05 MPa to 0.6 MPa for liquid media and up to 1 MPa for gaseous media, utilizing a solenoid coil type MD-... that can be ordered as an accessory. Submit your exact part number, quantity, and application requirements to receive a quote for this component.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 546157
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 546157.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Structural design
- Diaphragm valve | Servo-controlled
- Actuation type
- Electrical
- Sealing principle
- Soft
- Mounting position
- Preferably upright
- Type of mounting
- In-line installation
- Fitting connection
- 3/4 NPT
- Electrical connection
- Solenoid coil type MD-... , coil can be ordered as an accessory
- Nominal width
- 27.5 mm
- Valve function
- 2/2-way, closed, monostable
- Flow direction
- Non-reversible
- Medium
- Compressed air as per ISO 8573-1:2010 [7:4:4] | Inert gas | Water | Neutral liquids
- Medium pressure of liquid media
- 0.05 MPa...0.6 MPa | 0.5 bar...6 bar | 7.25 psi...87 psi
- Medium pressure of gaseous media
- 0.05 MPa...1 MPa | 0.5 bar...10 bar | 7.25 psi...145 psi
- Burst pressure
- 4 MPa | 40 bar | 580 psi
- Overload pressure
- 3.5 MPa | 35 bar | 507.5 psi
- Pressure difference
- 0.05 MPa | 7.25 psi
- Differential pressure
- 0.5 bar
