Reference imageConfirm configuration by manufacturer part number.
Festo
546749
Distributor FR-8-1/8-BR
The Festo 546749 is an industrial component featuring a wrought aluminum alloy housing with one G3/8 supply line and eight G1/8 outlets at an 8.6 mm nominal width. This part operates with compressed air as per ISO 8573-1:2010 [7:-:-] across a 0 bar to 16 bar operating pressure range in any mounting position, allowing oil lubrication operation that is required for further use. Built with a CRC rating of 2 for moderate corrosion stress and VDMA24364-B1/B2-L LABS conformity, the assembly functions reliably within specified parameters. Submit the exact part number, quantity, and application requirements for a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 546749
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 546749.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Nominal width
- 8.6 mm
- Mounting position
- Any
- Operating pressure for entire temperature range
- 0 bar...16 bar
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:-:-]
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- No. of outlets
- 8
- No. of supply lines
- 1
- Pneumatic connection 1
- G3/8
- Pneumatic connection 2
- G1/8
- Housing material
- Wrought aluminum alloy
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 546749. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
