Name: Festo 549403 Pneumatic counter CCES-P-C8-E
Brand: Festo

Pneumatic counter CCES-P-C8-E

The Festo 549403 is an electrical adding counter featuring an 8-digit display, internal lithium battery power supply, and front panel mounting. This component achieves a maximum counting rate of 7.5 kHz alongside a maximum attenuated counting rate of 30 Hz, utilizing manual button or electrical signal reset methods with a minimum pulse length of 15 ms. Designed with a moderate corrosion resistance class (CRC 2) and RoHS compliance, it operates within an ambient temperature range of -10 °C to 50 °C and features a programmable clock pulse input with negative edge 30Hz settings. Submit the exact part number, quantity, and application requirements to request a quote for this 30 g industrial component.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 549403
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 549403.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Structural design: Electrical adding counter with battery
Reset method: Manual button or electrical signal
Display: 8 digit
Max. counting rate: 7.5 kHz
Max. attenuated counting rate: 30 Hz
Min. pulse length for actuator: 15 ms
Min. pulse length for reset: 15 ms
Upper threshold value DC: 5 V...30 V
Power supply: Lithium battery
Lower threshold value DC: 0.7 V
CE marking (see declaration of conformity): As per EU EMC directive
UKCA marking (see declaration of conformity): To UK instructions for EMC
Corrosion resistance class (CRC): 2 - Moderate corrosion stress
LABS (PWIS) conformity: VDMA24364-B1/B2-L
Ambient temperature: -10 °C...50 °C
Product weight: 30 g
Clock pulse input setting: negative edge 30Hz
Clock pulse input (input): Programmable
Type of mounting: Front panel mounting
Note on materials: RoHS compliant
Housing material: PC

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 549403. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
