552170

Name: Festo 552170 Desiccant air dryer PDAD-09-G3/8
Brand: Festo

Desiccant air dryer PDAD-09-G3/8

The Festo 552170 is a cold-regenerating adsorption dryer featuring a vertical or horizontal mounting position, an inlet pressure range of 4 bar to 16 bar, and a standard pressure dew point of -40 °C that drops to -70 °C at a reduced flow rate. This unit operates with compressed air as per ISO 8573-1:2010 [6:-:4], prohibiting oil lubrication and liquid water, while delivering output air quality meeting ISO 8573-1:2010 [2:2:2] at -40 °C and [2:1:2] at -70 °C. It provides IP65 protection, holds a corrosion resistance class of CRC 2, and consumes 9.6 W at 24 VDC or 16 VA with 230 VAC under contamination level 2 conditions. Submit the exact part number, quantity, and application requirements to request a quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 552170
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 552170.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Mounting position: Vertical | Horizontal
Structural design: Cold-regenerating adsorption dryer
Inlet pressure 1: 4 bar...16 bar
Power consumption at 24 VDC: 9.6 W
Power consumption with 230 VAC: 16 VA
Contamination level: 2
KC characters: KC-EMV
CE marking (see declaration of conformity): As per EU EMC directive | As per EU low voltage directive
UKCA marking (see declaration of conformity): To UK instructions for EMC | To UK instructions for electrical equipment
Operating medium: Compressed air as per ISO 8573-1:2010 [6:-:4]
Information on operating and pilot media: Operation with oil lubrication not possible | No water in liquid form
Pressure dew point: -40 °C
Pressure dew point for reduced rate of ow: -70 °C
Corrosion resistance class (CRC): 2 - Moderate corrosion stress
LABS (PWIS) conformity: VDMA24364-B1/B2-L
Storage temperature: -20 °C...60 °C
Air quality class at the output: Compressed air as per ISO 8573-1:2010 [2:1:2] at -70°C | Compressed air as per ISO 8573-1:2010 [2:2:2] at -40°C
Temperature of medium: 2 °C...50 °C
Degree of protection: IP65
Protection class: II
Overvoltage category: II
Ambient temperature: 5 °C...50 °C
Product weight: 13000 g
Electrical connection 1, function: Power supply AC
Electrical connection 1, connection type: Socket
Electrical connection 1, connection technology: Connection pattern type C as per industry standard, 9.4 mm
Electrical connection 1, number of pins/wires: 3
Electrical connection 1, occupied pins/wires: 2

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 552170. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
