Reference imageConfirm configuration by manufacturer part number.
Festo
552171
Desiccant air dryer PDAD-13-G3/8
The Festo part number 552171 is a cold-regenerating adsorption dryer featuring vertical or horizontal mounting positions, an inlet pressure range of 4 bar to 16 bar, and a pressure dew point of -40 °C that reaches -70 °C at a reduced flow rate. This component operates on compressed air per ISO 8573-1:2010 [6:-:4] with an IP65 degree of protection, power consumption of 9.6 W at 24 VDC or 16 VA at 230 VAC, and moderate corrosion resistance class 2. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 552171
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 552171.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Mounting position
- Vertical | Horizontal
- Structural design
- Cold-regenerating adsorption dryer
- Inlet pressure 1
- 4 bar...16 bar
- Power consumption at 24 VDC
- 9.6 W
- Power consumption with 230 VAC
- 16 VA
- Contamination level
- 2
- KC characters
- KC-EMV
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU low voltage directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK instructions for electrical equipment
- Operating medium
- Compressed air as per ISO 8573-1:2010 [6:-:4]
- Information on operating and pilot media
- Operation with oil lubrication not possible | No water in liquid form
- Pressure dew point
- -40 °C
- Pressure dew point for reduced rate of ow
- -70 °C
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Storage temperature
- -20 °C...60 °C
- Air quality class at the output
- Compressed air as per ISO 8573-1:2010 [2:1:2] at -70°C | Compressed air as per ISO 8573-1:2010 [2:2:2] at -40°C
- Temperature of medium
- 2 °C...50 °C
- Degree of protection
- IP65
- Protection class
- II
- Overvoltage category
- II
- Ambient temperature
- 5 °C...50 °C
- Product weight
- 14000 g
- Electrical connection 1, function
- Power supply AC
- Electrical connection 1, connection type
- Socket
- Electrical connection 1, connection technology
- Connection pattern type C as per industry standard, 9.4 mm
- Electrical connection 1, number of pins/wires
- 3
- Electrical connection 1, occupied pins/wires
- 2
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 552171. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
