Reference imageConfirm configuration by manufacturer part number.
Festo
552175
Desiccant air dryer PDAD-100-G1/2
The Festo 552175 is a cold-regenerating adsorption dryer featuring a structural design capable of vertical or horizontal mounting positions, operating within an inlet pressure range of 4 bar to 16 bar. This component functions with compressed air as per ISO 8573-1:2010 [6:-:4], achieving a pressure dew point of -40 °C or -70 °C for a reduced rate of flow, and provides a degree of protection of IP65 with Class II protection. Compliance is established via CE and UKCA markings as per respective directives for pressure equipment, EMC, and low voltage, alongside a corrosion resistance class of CRC 2 and VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to request a quote for this component.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 552175
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 552175.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Mounting position
- Vertical | Horizontal
- Structural design
- Cold-regenerating adsorption dryer
- Inlet pressure 1
- 4 bar...16 bar
- Power consumption at 24 VDC
- 9.6 W
- Power consumption with 230 VAC
- 16 VA
- Contamination level
- 2
- KC characters
- KC-EMV
- CE marking (see declaration of conformity)
- as per EU pressure equipment directive | As per EU EMC directive | As per EU low voltage directive
- UKCA marking (see declaration of conformity)
- according to UK regulations for pressure equipment | To UK instructions for EMC | To UK instructions for electrical equipment
- Operating medium
- Compressed air as per ISO 8573-1:2010 [6:-:4]
- Information on operating and pilot media
- Operation with oil lubrication not possible | No water in liquid form
- Pressure dew point
- -40 °C
- Pressure dew point for reduced rate of ow
- -70 °C
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Storage temperature
- -20 °C...60 °C
- Air quality class at the output
- Compressed air as per ISO 8573-1:2010 [2:1:2] at -70°C | Compressed air as per ISO 8573-1:2010 [2:2:2] at -40°C
- Temperature of medium
- 2 °C...50 °C
- Degree of protection
- IP65
- Protection class
- II
- Overvoltage category
- II
- Ambient temperature
- 5 °C...50 °C
- Product weight
- 47000 g
- Electrical connection 1, function
- Power supply AC
- Electrical connection 1, connection type
- Socket
- Electrical connection 1, connection technology
- Connection pattern type C as per industry standard, 9.4 mm
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 552175. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
