Festo
553575
Connecting cable NEBV-M12G8-K-2-M12G4
This Festo industrial component, part number 553575, conforms to standard EN 61076-2-101 and operates within an AC and DC voltage range of 0 V to 30 V. The field device side features a straight M12x1 A-coded socket with 8 pins, 4 occupied pins, and a screw-type lock, while the control side incorporates a straight M12x1 A-coded plug with 4 pins, 4 occupied pins, and a screw-type lock, supplied without a label holder. Please submit the exact part number, quantity, and application requirements to receive a formal quotation.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 553575
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 553575.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Conforms to standard
- EN 61076-2-101
- Cable designation
- Without label holder
- Electrical connection 1, function
- Field device side
- Electrical connection 1, design
- Round
- Electrical connection 1, connection type
- Socket
- Electrical connection 1, cable outlet
- Straight
- Electrical connection 1, connection technology
- M12x1 A-coded as per EN 61076-2-101
- Electrical connection 1, number of pins/wires
- 8
- Electrical connection 1, occupied pins/wires
- 4
- Electrical connection 1, type of mounting
- Screw-type lock
- Electrical connection 2, function
- Control side
- Electrical connection 2, design
- Round
- Electrical connection 2, connection type
- Plug
- Electrical connection 2, cable outlet
- Straight
- Electrical connection 2, connection technology
- M12x1 A-coded as per EN 61076-2-101
- Electrical connection 2, number of pins/wires
- 4
- Electrical connection 2, occupied pins/wires
- 4
- Electrical connection 2, type of mounting
- Screw-type lock
- DC operating voltage range
- 0 V...30 V
- Operating voltage range AC
- 0 V...30 V
- Current rating at 40° C
- 2 A
- Surge resistance
- 0.8 kV
- Shield
- Yes
- Cable length
- 2 m
- Cable characteristic
- Standard
- Bending radius, xed cable installation
- 29 mm
- Bending radius, exible cable installation
- 58 mm
- Cable diameter
- 5.6 mm
- Cable diameter tolerance
- ± 0.2 mm
- Cable design
- 4 x 0.34 mm²
