Name: Festo 560706 Air solenoid valve VOVG-S12-M32U-AH-M5-1H3
Brand: Festo

Air solenoid valve VOVG-S12-M32U-AH-M5-1H3

The Festo part number 560706 is a 12 mm wide electrical industrial component featuring a 3/2-way, monostable, open valve function with a piston gate valve structural design and soft sealing principle. Operating at 24V DC with an operating pressure range of 0.2 MPa to 0.8 MPa (2 bar to 8 bar, 29 psi to 116 psi), this piloted valve delivers a normal nominal flow rate of 180 l/min through a sub-base pneumatic working port and features an adjustable exhaust air function, a pneumatic spring reset method, and IP40 protection. Submit the exact part number, quantity, and application requirements to request a quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 560706
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 560706.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Valve function: 3/2-way, monostable, open
Actuation type: Electrical
Width: 12 mm
Normal nominal ow rate (normalized to DIN 1343): 180 l/min
Pneumatic working port: Sub-base
Operating voltage: 24V DC
Operating pressure: 0.2 MPa...0.8 MPa | 2 bar...8 bar | 29 psi...116 psi
Structural design: Piston gate valve
Reset method: Pneumatic spring
Degree of protection: IP40
Nominal width: 2.1 mm
Exhaust air function: Adjustable
Sealing principle: Soft
Mounting position: Any
Manual override: Non-detenting
Type of control: Piloted
Flow direction: Non-reversible
Lap: Positive overlap
Switching time oﬀ: 10 ms
On switching time: 12 ms
Coil characteristics: 24 V DC: 1.0 W
Operating medium: Compressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot media: Operation with oil lubrication possible (required for further use)
Corrosion resistance class (CRC): 0 - No corrosion stress
LABS (PWIS) conformity: VDMA24364-B2-L
Temperature of medium: -5 °C...50 °C
Pilot medium: Compressed air as per ISO 8573-1:2010 [7:4:4]
Ambient temperature: -5 °C...50 °C
Electrical connection: 2-pin | Plug

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 560706. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
