Festo
560941
End plate VMPAL-EPL-SD44-IP40
The Festo part number 560941 is an industrial component featuring a width of 43 mm, a length of 107.3 mm, and a product weight of 190 g. Designed with a valve manifold architecture supporting interchangeable valve sizes, it accommodates a maximum of 32 valve positions and 32 solenoid coils, operating within a pressure range of -0.09 MPa to 1 MPa and a nominal DC voltage of 24 V. It includes a 44-pin Sub-D multi-pin plug electrical connection and provides an IP40 degree of protection in the mounted state alongside a CRC 3 high corrosion stress rating. Submit the exact part number, quantity, and application requirements for a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 560941
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 560941.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Width
- 43 mm
- Length
- 107.3 mm
- Max. no. of valve positions
- 32
- Valve manifold design
- Interchangeable valve sizes
- Max. no. of solenoid coils
- 32
- Operating pressure
- -0.09 MPa...1 MPa | -0.9 bar...10 bar
- Pilot pressure MPa
- 0.3 MPa...0.8 MPa
- Pilot pressure
- 3 bar...8 bar
- Nominal operating voltage DC
- 24 V
- Corrosion resistance class (CRC)
- 3 - High corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Degree of protection
- IP40
- Note on degree of protection
- In mounted state
- Ambient temperature
- -5 °C...50 °C
- Product weight
- 190 g
- Electrical connection 1, function
- Multi-pin
- Electrical connection 1, connection type
- Plug
- Electrical connection 1, connection technology
- Sub-D
- Electrical connection 1, number of pins/wires
- 44
- Note on materials
- RoHS compliant
- End plate material
- Die-cast aluminum | PA-reinforced
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 560941. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
