Confirm the exact configuration
Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.
Global industrial sourcing · Houston, Texas info@mropartsrfq.com
Reference imageConfirm configuration by manufacturer part number.
Festo
562534
Branching module MS9-FRM
The Festo 562534 is an industrial branching module of size 9 from the MS series, featuring a pressure gauge set up for G1/4 and G1/8 with a red/green scale, pressure sensor, and switching indicator. It operates within a pressure range of 0 bar to 20 bar, supports a standard nominal flow rate in main flow direction 1 to 2 from 10000 l/min to 50000 l/min, and accommodates AC operating voltages from 0 V to 250 V alongside DC operating voltages from 0 V to 125 V using compressed air as per ISO 8573-1:2010 [7:4:4] with lubricated operation possible. Certified with c UL us - recognized (OL), ATEX, and UKEX markings, this component is rated for Zone 1, Zone 2, Zone 21, and Zone 22 explosive environments with an explosive ambient temperature range of -10°C ≤ Ta ≤ +60°C. Submit the exact part number, quantity, and application requirements for an official quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 562534
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 562534.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Size
- 9
- Series
- MS
- Structural design
- Branching module
- Pressure gauge
- Set up for G1/4 | Set up for G1/8 | Red/green scale | With pressure sensor | with pressure gauge | With switching indicator
- Operating pressure
- 0 bar...20 bar
- Standard nominal ow rate in main ow direction 1 -> 2
- 10000 l/min...50000 l/min
- Operating voltage range AC
- 0 V...250 V
- DC operating voltage range
- 0 V...125 V
- Certication
- c UL us - recognized (OL)
- CE marking (see declaration of conformity)
- as per EU explosion protection directive (ATEX)
- UKCA marking (see declaration of conformity)
- acc. to UK EX instructions
- Explosion protection certication outside the EU
- EPL Db (GB) | EPL Gb (GB)
- Explosion prevention and protection
- Zone 1 (ATEX) | Zone 1 (UKEX) | Zone 2 (ATEX) | Zone 21 (ATEX) | Zone 21 (UKEX) | Zone 22 (ATEX)
- ATEX category gas
- II 2G
- ATEX category for dust
- II 2D
- Type of ignition protection for gas
- Ex h IIC T6 Gb X
- Type of (ignition) protection for dust
- Ex h IIIC T60°C Db X
- Explosive ambient temperature
- -10°C <= Ta <= +60°C
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:4:4]
- Information on operating and pilot media
- Lubricated operation possible
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Cleanroom suitability, measured according to ISO 14644-14
- Class 7 according to ISO 14644-1
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 562534. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
