Reference imageConfirm configuration by manufacturer part number.
Festo
565933
Input module CPX-P-8DE-N
The Festo industrial component, part number 565933, measures 50 mm in width, 107 mm in length, and 70 mm in height including the interlinking block and connection system, with a product weight of 100 g. Designed for mounting on interlinking block CPX-M-GE..., it operates in ambient temperatures from -5 °C to 50 °C and storage temperatures from -20 °C to 70 °C at a relative air humidity of 95% non-condensing. Built with a PA-reinforced and PC housing featuring RoHS-compliant materials and VDMA24364 zone III LABS conformity, the unit includes LED indicators for 1 group diagnostics, 8 channel diagnostics, and 8 channel status, alongside DIL switch control elements and a max cable length of 200 m. Diagnostics cover wire break, limit value violation, short circuit, and parameterization error per channel, while parameterization includes settings for data format, input debouncing time, input function, replacement value, signal extension, gate time, limit value monitoring, short circuit monitoring, parameter monitoring, counter configuration, upper and lower limits, and wire break monitoring per channel. Submit the exact part number, quantity, and application requirements for a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 565933
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 565933.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Dimensions W x L x H
- (incl. interlinking block and connection system) | 50 mm x 107 mm x 70 mm
- Width dimension
- 50 mm
- Type of mounting
- On interlinking block CPX-M-GE...
- Product weight
- 100 g
- Ambient temperature
- -5 °C...50 °C
- Storage temperature
- -20 °C...70 °C
- Relative air humidity
- 95 % | Non-condensing
- Degree of protection
- Depends on manifold block
- Max. cable length
- 200 m
- LABS (PWIS) conformity
- VDMA24364 zone III
- Note on materials
- RoHS-compliant
- Housing material
- PA-reinforced | PC
- LED indicators
- 1 group diagnostics | 8 channel diagnostics | 8 channel status
- Diagnostics
- Wire break per channel | Limit value violation per channel | Short circuit per channel | Parameterization error
- Control elements
- DIL switch
- Parameterization
- Data format | Input debouncing time per channel | Input function per channel | Replacement value in diagnostic case per channel | Signal extension time per channel | Gate time per channel | Limit value monitoring per channel | Short circuit monitoring per channel | Parameter monitoring | Counter conguration per channel | Upper limit per channel | Lower limit value per channel | Wire break monitoring per channel
