Festo
570038
Bus node CTEU-CO
The Festo part number 570038 is an industrial component utilizing the CANopen protocol with dimensions of 40 mm by 91 mm by 50 mm and a product weight of 90 g. Featuring a PA housing, it mounts on an electrical interface or sub-base and provides IP65 and IP67 protection in the mounted state with unused connections sealed, along with a corrosion resistance class of CRC 2. It includes product-specific and bus-specific LED displays for monitoring operating voltage, system status, I/O status, and network status, backed by diagnostics for communication errors, system diagnostics, and undervoltage. Submit the exact part number, quantity, and application requirements for an RFQ quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 570038
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 570038.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Protocol
- CANopen
- Dimensions W x L x H
- 40 mm x 91 mm x 50 mm
- Width dimension
- 40 mm
- Type of mounting
- On electrical interface | on the electrical sub-base
- Product weight
- 90 g
- Ambient temperature
- 0 °C...50 °C
- Storage temperature
- -20 °C...70 °C
- Degree of protection
- IP65 | IP67
- Note on degree of protection
- In mounted state | Unused connections sealed
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364 Zone III
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- KC characters
- KC-EMV
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- Note on materials
- RoHS compliant
- Housing material
- PA
- LED display (product-specic)
- PS: operating voltage for electronics and load supply | X1: module system status at I-Port 1 | X2: module system status at I-Port 2
- LED display (bus-specic)
- IO: I/O status | MNS: Network status
- Diagnostics
- Communication error | System diagnostics | Undervoltage
- Control elements
- DIL switch
