Festo
572556
Bus node CTEU-EC
The Festo part number 572556 is an industrial component utilizing the EtherCAT protocol with dimensions of 40 mm x 91 mm x 50 mm, a width of 40 mm, and a product weight of 90 g. It features PA housing material, an IP65 or IP67 degree of protection when mounted with unused connections sealed, and supports mounting on an electrical interface or electrical sub-base. The unit operates within a 0 ÞgC to 50 ÞgC ambient temperature range, withstands moderate corrosion stress with a CRC of 2, and includes specific LED displays and diagnostic capabilities for communication and system status. Please submit the exact part number, quantity, and application requirements to receive a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 572556
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 572556.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Protocol
- EtherCAT
- Dimensions W x L x H
- 40 mm x 91 mm x 50 mm
- Width dimension
- 40 mm
- Type of mounting
- On electrical interface | on the electrical sub-base
- Product weight
- 90 g
- Ambient temperature
- 0 °C...50 °C
- Storage temperature
- -20 °C...70 °C
- Degree of protection
- IP65 | IP67
- Note on degree of protection
- In mounted state | Unused connections sealed
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364 Zone III
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- KC characters
- KC-EMV
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- Note on materials
- RoHS compliant
- Housing material
- PA
- LED display (product-specic)
- PS: operating voltage for electronics and load supply | X1: module system status at I-Port 1 | X2: module system status at I-Port 2
- LED display (bus-specic)
- L/A1: Network active port 1 | L/A2: Network active port 2 | Run: Communication status
- Diagnostics
- Communication error | System diagnostics | Undervoltage
- Control elements
- DIL switch
