Festo
574012
Control block VOFA-L26-T32C-M-G14-1C1-ANP
The Festo 574012 is a 65 mm wide electrical industrial component featuring a 3/2-way closed, monostable piston gate valve design with a mechanical spring reset and soft sealing principle. It delivers a normal nominal flow rate of 1050 l/min through a G1/4 pneumatic working port across an operating pressure range of 0.3 MPa to 1 MPa (3 bar to 10 bar, 43.5 psi to 145 psi) at an operating voltage of 24V DC. Certified with c UL us - recognized (OL), KC-EMV, CE marking, and UKCA marking, this IP65 and NEMA 4 rated unit conforms to EN 60947-5-2, features adjustable exhaust air function, and supports any mounting position without manual override. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 574012
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 574012.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Valve function
- 3/2-way, closed, monostable
- Actuation type
- Electrical
- Width
- 65 mm
- Normal nominal ow rate (normalized to DIN 1343)
- 1050 l/min
- Pneumatic working port
- G1/4
- Operating voltage
- 24V DC
- Operating pressure
- 0.3 MPa...1 MPa | 3 bar...10 bar | 43.5 psi...145 psi
- Structural design
- Piston gate valve
- Reset method
- Mechanical spring
- Degree of protection
- IP65 | NEMA 4
- Certication
- c UL us - recognized (OL)
- KC characters
- KC-EMV
- CE marking (see declaration of conformity)
- As per EU EMC directive | as per EU machinery directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK instructions for machines
- Certicate issuing authority
- UL MH19482
- Exhaust air function
- Adjustable
- Sealing principle
- Soft
- Mounting position
- Any
- Conforms to standard
- EN 60947-5-2
- Manual override
- None
- Type of control
- Piloted
- Pilot air supply port
- Internal
- Flow direction
- Non-reversible
- Measuring principle
- Inductive
- Lap
- Positive overlap
- Sensor reverse polarity protection
- For all electrical connections
- Safety function
- Exhausting | Tamper protection, protection against unexpected start-up
