Festo
575667
End plate VMPAL-EPL-IPO32
The Festo 575667 is an industrial component featuring an interchangeable valve design supporting a maximum of 32 valve positions and 32 solenoid coils, operating across a pressure range of -0.9 bar to 10 bar with a pilot pressure of 3 bar to 8 bar. This unit operates on a nominal DC voltage of 24 V with an intrinsic current consumption of 30 mA for both operating and load voltages, and supports I-Port and IO-Link communication protocols. Built with a CRC rating of 3 for high corrosion stress and IP65/IP67 protection in the mounted state, it measures 64.8 mm wide by 107.3 mm long and includes reverse polarity protection for the operating voltage along with load supply undervoltage diagnostics. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 575667
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 575667.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Width
- 64.8 mm
- Length
- 107.3 mm
- Reverse polarity protection
- For operating voltage
- Mounting position
- Any
- Diagnostics
- Load supply undervoltage
- Max. no. of valve positions
- 32
- Valve manifold design
- Interchangeable valve sizes
- Max. no. of solenoid coils
- 32
- Operating pressure
- -0.09 MPa...1 MPa | -0.9 bar...10 bar
- Pilot pressure MPa
- 0.3 MPa...0.8 MPa
- Pilot pressure
- 3 bar...8 bar
- Intrinsic current consumption at load voltage
- 30 mA
- Intrinsic current consumption at operating voltage
- 30 mA
- Nominal operating voltage DC
- 24 V
- Protocol
- I-Port | IO-Link®
- Corrosion resistance class (CRC)
- 3 - High corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Storage temperature
- -20 °C...40 °C
- Degree of protection
- IP65 | IP67
- Note on degree of protection
- In mounted state
- Ambient temperature
- -5 °C...50 °C
- Product weight
- 170 g
- IO-Link®, protocol version
- Device V 1.0
- IO-Link®, communication mode
- COM2 (38.4 kBd), COM3 (230.4 kBd)
- IO-Link®, port class
- B
- IO-Link®, number of ports
- 1
- IO-Link®, process data width OUT
- 1 - 4 bytes
