Festo
6411
Distributor block FR-8-1/2
The Festo 6411 is an industrial component featuring a die-cast aluminum housing with 1 supply line via an internal thread G3/4 and 8 outlets via internal threads G1/2, providing a nominal width of 18.6 mm and a product weight of 1000 g. This part operates with compressed air as per ISO 8573-1:2010 [7:-:-] across an operating pressure range of 0 bar to 16 bar and an ambient temperature range of -10 °C to 60 °C, allowing for any mounting position and oil-lubricated operation. It requires a nominal tightening torque of 35 Nm with a tolerance of ±10%, exhibits a corrosion resistance class of CRC 0 with VDMA24364-B1/B2-L LABS conformity, and includes RoHS-compliant materials. Submit the exact part number, quantity, and application requirements for a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 6411
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 6411.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Nominal width
- 18.6 mm
- Mounting position
- Any
- Operating pressure for entire temperature range
- 0 bar...16 bar
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:-:-]
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- Corrosion resistance class (CRC)
- 0 - No corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Ambient temperature
- -10 °C...60 °C
- Nominal tightening torque
- 35 Nm
- Tolerance for nominal tightening torque
- ±10%
- Product weight
- 1000 g
- No. of outlets
- 8
- No. of supply lines
- 1
- Pneumatic connection 1
- Internal thread G3/4
- Pneumatic connection 2
- Internal thread G1/2
- Note on materials
- RoHS compliant
- Housing material
- Die-cast aluminum
