Reference imageConfirm configuration by manufacturer part number.
Festo
8022569
Electric cylinder ESBF-...-32- -
The Festo 8022569 is an ISO 15552 compliant electric cylinder featuring a size 32 profile, an adjustable stroke from 30 mm to 800 mm, and an M10x1.25 piston rod thread. Engineered with a plain bearing-guide for torsion protection, this unit supports a 100% duty cycle and accommodates either stepper or servo motors with position sensing via proximity switch. It offers corrosion resistance classes 2 and 3, LABS conformity to VDMA24364 Zone III, and ISO 14644-1 Class 7 cleanroom suitability alongside reduced Cu/Zn/Ni material variants for Li-ion battery production. Submit the exact part number, quantity, and application requirements to request a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8022569
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8022569.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Size
- 32
- Stroke
- 30 mm...800 mm
- Piston rod thread
- M10x1.25
- Screw diameter
- 12 mm
- Max. angle of rotation of the piston rod +/-
- 0.25 deg
- Based on norm
- ISO 15552
- Mounting position
- Any
- Motor type
- Stepper motor | Servo motor
- Position sensing
- Via proximity switch
- Structural design
- Electric cylinder with ball screw | Electric cylinder with lead screw spindle
- Variants
- Metals with copper, zinc or nickel by mass as main constituent are | excluded from use. Exceptions are nickel in steel, chemically nickel- | plated surfaces, printed circuit boards, cables, electrical plug connectors | and coils.
- Protection against torsion/guide
- With plain bearing-guide
- Duty cycle
- 100%
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress | 3 - High corrosion stress
- LABS (PWIS) conformity
- VDMA24364 Zone III
- Suitability for the production of Li-ion batteries
- Suitable for battery production with reduced Cu/Zn/Ni values (F1a)
- Cleanroom suitability, measured according to ISO 14644-14
- Class 7 according to ISO 14644-1
- Storage temperature
- -20 °C...60 °C
- For use in the food industry
- See supplementary material information
- Relative air humidity
- 0 - 95%
- Degree of protection
- IP40 | IP65
- Ambient temperature
- 0 °C...60 °C
- Max. radial force on actuator shaft
- 115 N
- Max. feed force Fx
- 1000 N
- No-load driving torque
- 0.1 Nm
- Type of mounting
- With internal thread | or accessories
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8022569. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
