Name: Festo 8022878 Solenoid coil VACN-H1-A1-2A
Brand: Festo

Solenoid coil VACN-H1-A1-2A

The Festo part number 8022878 is an industrial component featuring a 100% duty cycle, any mounting position, and a coil characteristic of 110 V AC at 50/60 Hz with a pick-up power of 36.0 VA and holding power of 18.5 VA. It operates within an ambient temperature range of -20 °C to 50 °C, provides IP65 degree of protection in the mounted state, and achieves a corrosion resistance class of CRC 4 for particularly high corrosion stress alongside VDMA24364 Zone III LABS conformity. This unit weighs 150 g, withstands a 2.5 kV surge resistance at contamination level 3, and accommodates permissible voltage and frequency fluctuations of +/- 10% under CE and UKCA directives. Submit the exact part number, quantity, and application requirements to request a quote for this component.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 8022878
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 8022878.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Mounting position: Any
Switching position indication: No
Min. pick-up time: 12 ms
Duty cycle: 100%
Power factor cos {phi}: 0.7
Coil characteristics: 110 V AC: 50/60 Hz, pick-up power 36.0 VA, holding power 18.5 VA
Surge resistance: 2.5 kV
Contamination level: 3
Permissible frequency uctuations: +/- 10%
Permissible voltage uctuations: +/- 10%
CE marking (see declaration of conformity): As per EU low voltage directive
UKCA marking (see declaration of conformity): To UK instructions for electrical equipment
Restricted ambient and media temperature: (for limited duty cycle) | -20 - 60 °C
Corrosion resistance class (CRC): 4 - Particularly high corrosion stress
LABS (PWIS) conformity: VDMA24364 Zone III
Degree of protection: IP65
Note on degree of protection: In mounted state
Ambient temperature: -20 °C...50 °C
Max. tightening torque of pneumatic tting: 2 Nm
Product weight: 150 g
Electrical connection: Type A | Plug | As per DIN EN 175301-803 | Rectangular design
Type of mounting: With locknut
Note on materials: RoHS compliant
Solenoid coil material: Copper | Steel | Thermoplast
Material of winding: Copper
