Reference imageConfirm configuration by manufacturer part number.
Festo
8022879
Solenoid coil VACN-H1-A1-3A
The Festo part number 8022879 is an industrial component featuring a 100% duty cycle, a minimum pick-up time of 12 ms, and a coil characteristic of 230 V AC at 50/60 Hz with a pick-up power of 36.0 VA and holding power of 18.9 VA. Built with a corrosion resistance class of 4 for particularly high corrosion stress and an IP65 degree of protection in the mounted state, this unit operates within an ambient temperature range of -20 °C to 50 °C and weighs 150 g. Submit the exact part number, quantity, and application requirements to receive a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8022879
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8022879.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Mounting position
- Any
- Switching position indication
- No
- Min. pick-up time
- 12 ms
- Duty cycle
- 100%
- Power factor cos {phi}
- 0.7
- Coil characteristics
- 230 V AC: 50/60 Hz, pick-up power 36.0 VA, holding power 18.9 VA
- Surge resistance
- 4 kV
- Contamination level
- 3
- Permissible frequency uctuations
- +/- 10%
- Permissible voltage uctuations
- +/- 10%
- CE marking (see declaration of conformity)
- As per EU low voltage directive
- UKCA marking (see declaration of conformity)
- To UK instructions for electrical equipment
- Restricted ambient and media temperature
- (for limited duty cycle) | -20 - 60 °C
- Corrosion resistance class (CRC)
- 4 - Particularly high corrosion stress
- LABS (PWIS) conformity
- VDMA24364 Zone III
- Degree of protection
- IP65
- Note on degree of protection
- In mounted state
- Ambient temperature
- -20 °C...50 °C
- Max. tightening torque of pneumatic tting
- 2 Nm
- Product weight
- 150 g
- Electrical connection
- Type A | Plug | As per DIN EN 175301-803 | Rectangular design
- Type of mounting
- With locknut
- Note on materials
- RoHS compliant
- Solenoid coil material
- Copper | Steel | Thermoplast
- Material of winding
- Copper
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8022879. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
