Reference imageConfirm configuration by manufacturer part number.
Festo
8025709
Flow control VFFG-T-M5-5
The Festo 8025709 is an industrial flow control valve featuring a threaded mounting type, a nominal width of 0.5 mm, and a standard nominal flow rate of 9.6 l/min in the flow control direction. Operating within a pressure range of -0.9 bar to 10 bar and an ambient temperature range of -5 °C to 60 °C, this component utilizes compressed air according to ISO 8573-1:2010 [7:4:4] and accommodates oil-lubricated operation. Weighing 0.5 g with a RoHS-compliant build and PA hollow bolt material, it conforms to VDMA24364-B1/B2-L LABS requirements. Submit the exact part number, quantity, and application requirements to request a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8025709
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8025709.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Valve function
- Flow control function
- Type of mounting
- With thread
- Standard nominal ow rate in ow control direction
- 9.6 l/min
- Operating pressure
- -0.9 bar...10 bar
- Ambient temperature
- -5 °C...60 °C
- Nominal width
- 0.5 mm
- b-value
- 0.5
- C value
- 0.04 l/sbar
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:4:4]
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Storage temperature
- -20 °C...60 °C
- Product weight
- 0.5 g
- Note on materials
- RoHS compliant
- Hollow bolt material
- PA
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8025709. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
