Festo
8025714
Flow control VFFG-T-M5-12
The Festo part number 8025714 is an industrial component featuring a flow control valve function and threaded mounting. It provides a standard nominal flow rate of 45.4 l/min in the flow control direction, an operating pressure range of -0.9 bar to 10 bar, and a nominal width of 1.2 mm. Operating with compressed air as per ISO 8573-1:2010 [7:4:4], this 0.5 g RoHS-compliant unit includes a PA hollow bolt and conforms to VDMA24364-B1/B2-L LABS standards. Submit the exact part number, quantity, and application requirements to receive a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8025714
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8025714.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Valve function
- Flow control function
- Type of mounting
- With thread
- Standard nominal ow rate in ow control direction
- 45.4 l/min
- Operating pressure
- -0.9 bar...10 bar
- Ambient temperature
- -5 °C...60 °C
- Nominal width
- 1.2 mm
- b-value
- 0.5
- C value
- 0.16 l/sbar
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:4:4]
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Storage temperature
- -20 °C...60 °C
- Product weight
- 0.5 g
- Note on materials
- RoHS compliant
- Hollow bolt material
- PA
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8025714. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
