Festo
8035555
Signal conditioner SCDN-2V-EC4-PNLK-L1
The Festo part number 8035555 is an industrial component measuring voltage across a 0 to 10 V signal range with an accuracy of 0.5 %FS and a repetition accuracy of 0.2 %FS at an ambient temperature of 0 °C to 50 °C. It features a typical sampling interval of 1 ms, two switchable PNP or NPN switching outputs with a maximum output current of 100 mA, short-circuit protection, and an IO-Link protocol version Device V 1.1 supporting the smart sensor profile. Compliance includes RCM, c UL us - Listed (OL) under certificate UL E322346, RoHS materials, and CE and UKCA markings for EMC and RoHS directives. Submit the exact part number, quantity, and application requirements for a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8035555
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8035555.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- Certicate issuing authority
- UL E322346
- Note on materials
- RoHS compliant
- Measured variable
- voltage
- Signal range
- 0 - 10 V
- Ambient temperature
- 0 °C...50 °C
- Typical sampling interval
- 1 ms
- Accuracy in ± % FS
- 0.5 %FS
- Repetition accuracy in ± %FS
- 0.2 %FS
- Switching output
- 2 x PNP or 2 x NPN switchable
- Switching function
- Freely programmable
- Switching element function
- N/C contact/N/O contact, switchable
- Max. output current
- 100 mA
- Short-circuit protection
- Yes
- Protocol
- IO-Link®
- IO-Link®, protocol version
- Device V 1.1
- IO-Link®, prole
- Smart sensor prole
- IO-Link®, function classes
- Binary data channel (BDC) | Process data variable (PDV) | Identication | Diagnostics | Teach channel
- IO-Link®, communication mode
- COM2 (38,4 kBd)
- IO-Link®, SIO mode support
- Yes
- IO-Link®, port class
- A
- IO-Link®, process data width OUT
- 0 bytes
- IO-Link®, process data width IN
- 5 Byte
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8035555. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
