Festo
8035556
Signal conditioner SCDN-2A-EC4-PNLK-L1
The Festo part number 8035556 is an industrial component measuring current within a 0 to 20 mA signal range at a typical sampling interval of 1 ms. Featuring 0.5 %FS accuracy, 0.2 %FS repetition accuracy, and 2 x PNP or 2 x NPN switchable switching outputs with short-circuit protection, this device integrates IO-Link protocol version Device V 1.1 supporting smart sensor profiles. It holds RCM compliance and c UL us - Listed (OL) certifications alongside CE and UKCA markings per EMC and RoHS directives, operating at an ambient temperature of 0 °C to 50 °C. Submit the exact part number, quantity, and application requirements to request a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8035556
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8035556.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- Certicate issuing authority
- UL E322346
- Note on materials
- RoHS compliant
- Measured variable
- current
- Signal range
- 0 - 20 mA
- Ambient temperature
- 0 °C...50 °C
- Typical sampling interval
- 1 ms
- Accuracy in ± % FS
- 0.5 %FS
- Repetition accuracy in ± %FS
- 0.2 %FS
- Switching output
- 2 x PNP or 2 x NPN switchable
- Switching function
- Freely programmable
- Switching element function
- N/C contact/N/O contact, switchable
- Max. output current
- 100 mA
- Short-circuit protection
- Yes
- Protocol
- IO-Link®
- IO-Link®, protocol version
- Device V 1.1
- IO-Link®, prole
- Smart sensor prole
- IO-Link®, function classes
- Binary data channel (BDC) | Process data variable (PDV) | Identication | Diagnostics | Teach channel
- IO-Link®, communication mode
- COM2 (38,4 kBd)
- IO-Link®, SIO mode support
- Yes
- IO-Link®, port class
- A
- IO-Link®, process data width OUT
- 0 bytes
- IO-Link®, process data width IN
- 5 Byte
