Festo
8067141
Vacuum generator VABF-S4-2-V2B1-G38-CB-VL-20-A
The Festo 8067141 industrial component features a 35 mm width, a 2 mm nominal width of the Laval nozzle, an open muffler construction type, and electrical actuation with reverse polarity protection for all electrical connections in any mounting position. It includes integrated functions such as an electric ejector pulse, flow control valve, electric on-off valve, electric air-saving function, check valve, open muffler, and vacuum switch, alongside a 5/3-way pressurized valve function, piezoresistive measuring principle for relative pressure, and a 2-digit LED display with LED indicators showing units in kPa. Configuration is handled via teach-in or parameter sets with a threshold value setting range of 0 kPa to 99 kPa, hysteresis setting range of 0 kPa to 90 kPa, signal status LED display, high suction flow standard ejector characteristics, and detenting, non-detenting, or covered manual override options. Submit the exact part number, quantity, and application requirements to request a formal quote for this item.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8067141
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8067141.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Width
- 35 mm
- Nominal width of Laval nozzle
- 2 mm
- Muffler construction type
- Open
- Actuation type
- Electrical
- Reverse polarity protection
- for all electrical connections
- Mounting position
- Any
- Ejector characteristics
- High suction ow | Standard
- Manual override
- Detenting | Non-detenting | Covered
- Measured variable
- Relative pressure
- Measuring principle
- Piezoresistive
- Switching function
- Window comparator | Threshold value comparator
- Integrated function
- Ejector pulse, electric | Flow control valve | Electric on-off valve | Electric air-saving function | Check valve | Muffler open | Vacuum switch
- Valve function
- 5/3-way, pressurized
- Display type
- LED | LED indicator | 2-digit
- Displayable unit(s)
- KPa
- Setting range threshold value
- 0 kPa...99 kPa
- Setting range hysteresis
- 0 kPa...90 kPa
- Setting options
- Teach-in | Via parameter sets
- Signal status display
- LED
