Festo
8067142
Vacuum generator VABF-S4-2-V2B1-G38-CB-VH-30-A
The Festo 8067142 is an industrial component featuring a 35 mm width and a 3 mm nominal width of Laval nozzle with an open muffler construction type. It includes electrical actuation with reverse polarity protection for all electrical connections, a 5/3-way pressurized valve function, and integrated functions comprising an electric ejector pulse, flow control valve, electric on-off valve, electric air-saving function, check valve, open muffler, and vacuum switch. Configured with piezoresistive measuring principles for relative pressure, it provides window comparator and threshold value comparator switching functions shown via an LED, LED indicator, and 2-digit display unit in kPa. Submit the exact part number, quantity, and application requirements for an RFQ quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8067142
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8067142.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Width
- 35 mm
- Nominal width of Laval nozzle
- 3 mm
- Muffler construction type
- Open
- Actuation type
- Electrical
- Reverse polarity protection
- for all electrical connections
- Mounting position
- Any
- Ejector characteristics
- High vacuum | Standard
- Manual override
- Detenting | Non-detenting | Covered
- Measured variable
- Relative pressure
- Measuring principle
- Piezoresistive
- Switching function
- Window comparator | Threshold value comparator
- Integrated function
- Ejector pulse, electric | Flow control valve | Electric on-off valve | Electric air-saving function | Check valve | Muffler open | Vacuum switch
- Valve function
- 5/3-way, pressurized
- Display type
- LED | LED indicator | 2-digit
- Displayable unit(s)
- KPa
- Setting range threshold value
- 0 kPa...99 kPa
- Setting range hysteresis
- 0 kPa...90 kPa
- Setting options
- Teach-in | Via parameter sets
- Signal status display
- LED
