Reference imageConfirm configuration by manufacturer part number.
Festo
8069773
Gateway CPX-IOT
Festo Gateway CPX-IOT, part number 8069773, is documented in the official Festo United States product data sheet. Review the technical specifications and operating conditions below when requesting a quotation.
Request pricing and availabilityCommercial response for your destination and required quantity.
Request a Quote- Manufacturer
- Festo
- Part number
- 8069773
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8069773.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationTechnical documents are stored and served from our system.
Verified configuration
Technical Specifications
Identification and family-level technical context are preserved from reviewed source evidence and official English-language manufacturer documentation.
- Dimensions W x L x H
- 50 mm x 107 mm x 50 mm
- Width dimension
- 50 mm
- Type of mounting
- With DIN rail
- Product weight
- 130 g
- Ambient temperature
- -5 °C...50 °C
- Storage temperature
- -20 °C...70 °C
- Relative air humidity
- 95% | Non-condensating
- Degree of protection
- IP65 | IP67
- Corrosion resistance class (CRC)
- 0 - No corrosion stress
- Vibration resistance
- Transport application test with severity level 1 as per FN 942017-4 and | EN 60068-2-6
- Shock resistance
- Shock test with severity level 1 as per FN 942017-5 and EN 60068-2-27
- Protection against direct and indirect contact
- PELV
- LABS (PWIS) conformity
- VDMA24364-B2-L
- CE marking (see declaration of conformity)
- As per EU EMC directive
- Note on materials
- RoHS compliant
- Housing material
- PA
- Diagnostics via LED
- Modify | Module location | Network status | Network status, port 1 | Network status, port 2 | Power supply for electronics/sensors | Load power supply | System fault | Connection to the cloud
- Control elements
- DIP switch for resetting to delivery state | Rotary switch for setting mode of operation
- IP address setting
- DHCP | Statically via web server
- Fieldbus interface, protocol
- Ethernet | OPC-UA
