Festo
8075671
Light barrier SOOE-TB-L-PNLK-T
The Festo 8075671 is a block-design optoelectronic through-beam sensor utilizing a red laser light with a working range of 0 mm to 20000 mm and a max. light spot of 50 mm at 20000 mm. Conforming to EN 60947-5-2 with RCM and c UL us - Listed (OL) certifications, this unit features a push-pull switching output, a max. switching frequency of 1250 Hz, and a max. output current of 100 mA within an ambient temperature range of -40 °C to 60 °C. It includes pulsed short-circuit protection, switchable PNP dark-switching or NPN light-switching functions, and timer functions accessible via IO-Link®. Submit the exact part number, quantity, and application requirements for a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8075671
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8075671.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Design
- Block design
- Conforms to standard
- EN 60947-5-2
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- Certicate issuing authority
- UL E232949
- Note on materials
- RoHS compliant
- Measuring principle
- Optoelectronic
- Detection method
- Through-beam sensor | Transmitter | Receiver
- Type of light
- Laser | Red
- Max. light spot
- 50 mm at 20000 mm
- Working range
- 0 mm...20000 mm
- Ambient temperature
- -40 °C...60 °C
- Switching output
- Push-pull
- Switching element function
- Switchable | PNP, dark-switching | NPN, light-switching
- Max. switching frequency
- 1250 Hz
- Max. output current
- 100 mA
- Voltage drop
- 0 V...1.5 V
- Timer function
- Via IO-Link®
- Short-circuit protection
- Pulsed
- Protocol
- IO-Link®
- IO-Link®, protocol version
- Device V 1.1
- IO-Link®, communication mode
- COM2 (38,4 kBd)
- IO-Link®, SIO mode support
- Yes
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8075671. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
