Reference imageConfirm configuration by manufacturer part number.
Festo
8086605
Digital input module CPX-AP-I-4DI-M8-3P
Manufactured by Festo under part number 8086605, this industrial component measures 30 mm in width, 102.5 mm in length, and 35 mm in height with a product weight of 81 g. Featuring through-hole mounting, a PA, PC, and nickel-plated die-cast zinc housing with NBR seals, and an IP65 or IP67 degree of protection when unused connections are sealed, the unit operates in ambient temperatures from -20 °C to 60 °C and relative air humidity up to 95% non-condensating. It carries CE, UKCA, KC, RCM, and c UL us - Listed certifications alongside RoHS compliance and VDMA24364-B2-L LABS conformity. Submit the exact part number, quantity, and application requirements for an official quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8086605
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8086605.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Dimensions W x L x H
- 30 mm x 102.5 mm x 35 mm
- Type of mounting
- With through-hole
- Product weight
- 81 g
- Ambient temperature
- -20 °C...60 °C
- Storage temperature
- -40 °C...70 °C
- Relative air humidity
- 5 - 95% | Non-condensating
- Degree of protection
- IP65 | IP67
- Note on degree of protection
- Unused connections sealed
- Corrosion resistance class (CRC)
- 1 - Low corrosion stress
- Max. cable length
- 30 m inputs | 50 m system communication
- LABS (PWIS) conformity
- VDMA24364-B2-L
- Cleanroom suitability, measured according to ISO 14644-14
- Statically installed element, no meaningful evaluation possible | according to ISO 14644-1
- CE marking (see declaration of conformity)
- As per EU EMC directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC
- KC characters
- KC-EMV
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- Certicate issuing authority
- UL E239998
- Note on materials
- RoHS compliant
- Housing material
- PA | PC | Die-cast zinc, nickel-plated
- Seals material
- NBR
- O-ring material
- FPM
- Diagnostics via LED
- Diagnostics per module | Status per channel
- Diagnose per internal communication
- Short circuit/overload in sensor supply | Electronics/sensors overvoltage | Electronics/sensors undervoltage
- Communication interface, function
- System communication XF10 IN
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8086605. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
