Festo
8087218
Balancer kit YHBP-
Engineered for demanding industrial motion applications, this Festo industrial component part number 8087218 supports lifting column and parallel kinematics systems with a stroke range of 100 mm to 1990 mm and a cylinder diameter between 50 mm and 200 mm. The unit operates within a pressure range of 0.4 MPa to 0.8 MPa utilizing compressed air conforming to ISO 8573-1:2010 [6:4:4], supporting a nominal DC operating voltage of 24 V with a 100% duty cycle and a maximum travel speed of 1 m/s. Designed with reverse polarity protection for operating voltage and an IP65 degree of protection in mounted state, the hardware accommodates loads from 25 kg to 999 kg and features a product weight ranging from 4.8 kg to 60.5 kg depending on configuration. Submit the exact part number, quantity, and application requirements to request a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8087218
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8087218.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Stroke range
- 100 mm...1990 mm
- Cylinder diameter
- 50 mm...200 mm
- Supported kinematics systems
- Lifting column | Parallel kinematics
- Reverse polarity protection
- For operating voltage
- Operating pressure
- 0.4 MPa...0.8 MPa | 4 bar...8 bar
- Max. travel speed
- 1 m/s
- DC operating voltage range
- 21.6 V...26.4 V
- Duty cycle
- 100%
- Nominal operating voltage DC
- 24 V
- Residual ripple
- 5%
- Current consumption with load-free outputs
- 2 A
- Operating medium
- Compressed air as per ISO 8573-1:2010 [6:4:4]
- LABS (PWIS) conformity
- VDMA24364 Zone III
- Storage temperature
- -20 °C...70 °C
- Degree of protection
- IP65
- Note on degree of protection
- IP20 for safety relay unit PNOZ | IP20 for control system CMCB-...-C | IP54 for control system CMCB-...-CC | In mounted state | IP20 for control unit CECC
- Ambient temperature
- 0 °C...50 °C
- Load
- 25 kg...999 kg
- Transmission ratio of kinematics
- 1:5 for lifting columns | 1:1 - 1:5 for parallel kinematics system
- Product weight
- 4.8 kg...60.5 kg
- Note on materials
- RoHS compliant
