Festo
8088779
Vacuum generator VABF-S4-2-V2B1-G38-CB-VL-14-A
The Festo 8088779 is an electrical industrial component featuring a 35 mm width and a 1.4 mm nominal width Laval nozzle with an open muffle construction type. This unit integrates an electric ejector pulse, flow control valve, electric on-off valve, electric air-saving function, check valve, open muffler, and vacuum switch, alongside a 5/3-way pressurized valve function supporting piezoresistive relative pressure measurement. It incorporates reverse polarity protection across all electrical connections, any mounting position capability, detenting, non-detenting, and covered manual overrides, as well as high suction flow standard ejector characteristics. Visual feedback is provided via an LED, LED indicator, and 2-digit display with a KPa displayable unit, 0 kPa to 99 kPa threshold value setting range, 0 kPa to 90 kPa hysteresis setting range, teach-in or parameter set setting options, and an LED signal status display supporting window and threshold value comparator switching functions. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8088779
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8088779.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Width
- 35 mm
- Nominal width of Laval nozzle
- 1.4 mm
- Muffler construction type
- Open
- Actuation type
- Electrical
- Reverse polarity protection
- for all electrical connections
- Mounting position
- Any
- Ejector characteristics
- High suction ow | Standard
- Manual override
- Detenting | Non-detenting | Covered
- Measured variable
- Relative pressure
- Measuring principle
- Piezoresistive
- Switching function
- Window comparator | Threshold value comparator
- Integrated function
- Ejector pulse, electric | Flow control valve | Electric on-off valve | Electric air-saving function | Check valve | Muffler open | Vacuum switch
- Valve function
- 5/3-way, pressurized
- Display type
- LED | LED indicator | 2-digit
- Displayable unit(s)
- KPa
- Setting range threshold value
- 0 kPa...99 kPa
- Setting range hysteresis
- 0 kPa...90 kPa
- Setting options
- Teach-in | Via parameter sets
- Signal status display
- LED
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8088779. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
