Festo
8091509
IO-Link Master USB CDSU-1
The Festo part number 8091509 is an industrial component supporting IO-Link protocol versions Master V 1.0 and Master V 1.1, with communication modes COM1, COM2, and COM3, alongside port classes A and B with accessories. It conforms to EN 61131-9 and requires the USB IO-Link Master Tool software for Windows 7 or above (32/64-bit), operating with an input voltage of 5 V DC at the USB connection or 24 V DC ± 6 V via external supply. Featuring an IP20 degree of protection, a product weight of 106 g, and an ambient temperature range of 0 °C to 55 °C, this unit includes reverse polarity and short-circuit protection while carrying RCM, CE, and UKCA compliance markings. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8091509
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8091509.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Conforms to standard
- EN 61131-9
- Application note
- for use with the USB IO-Link Master Tool software (available from the | support portal) for Windows version 7 or above (32/64-bit).
- Input voltage
- 5 V DC at the USB connection | 24 V DC ± 6 V via external supply
- Input current
- Max. 2.5 V DC via external supply | Max. 600 mA at the USB connection
- Output voltage
- 24 V DC ± 10% with USB operation | 24 V DC ± 6 V with external supply (max. input voltage)
- Reverse polarity protection
- for operating voltage connections
- Short-circuit protection
- Yes
- Overload protection
- Not available
- Certication
- RCM compliance mark
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- LABS (PWIS) conformity
- VDMA24364 Zone III
- Storage temperature
- -10 °C...75 °C
- Degree of protection
- IP20
- Ambient temperature
- 0 °C...55 °C
- Product weight
- 106 g
- Protocol
- IO-Link®
- IO-Link®, protocol version
- Master V 1.0 | Master V 1.1
- IO-Link®, communication mode
- COM1 (4.8 kBd), COM2 (38.4 kBd), COM3 (230.4 kBd)
- IO-Link®, port class
- A | B, with accessories
- IO-Link®, number of ports
- 1
- IO-Link®, process data width OUT
- 0–32 bytes congurable
- IO-Link®, process data width IN
- 0–32 bytes congurable
- IO-Link®, minimum cycle time
- 1.5 ms
- IO-Link®, data memory available
- 2 kB/port
