8096867

Name: Festo 8096867 Filter flow control CAMF-C6-FD-C6-11A
Brand: Festo

Filter flow control CAMF-C6-FD-C6-11A

The Festo part number 8096867 is an industrial component featuring an operating voltage range of 0 V to 600 V AC at a mains frequency of 50 Hz to 60 Hz, along with a nominal inductance of 3.7 mH at a 10% tolerance. Measuring 60 mm x 80 mm x 116 mm with a product weight of 940 g, this unit offers a 6 A current rating at 40° C and is designed for horizontal mounting on a mounting plate via a terminal strip electrical connection. It holds ENEC and c UL-Recognized (OL) certifications, carries CE marking as per the EU RoHS directive, and complies with VDMA24364 Zone III LABS conformity with an IP00 degree of protection. Submit the exact part number, quantity, and application requirements to receive a quote for this component.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 8096867
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 8096867.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Short-circuit protection: No
Current rating at 40° C: 6 A
Operating voltage range AC: 0 V...600 V
Nominal inductance: 3.7 mH
Nominal inductance tolerance: 10 %
Mains frequency: 50 Hz...60 Hz
Insulation voltage: 4000 V
Dimensions W x L x H: 60 mm x 80 mm x 116 mm
Certication: ENEC | c UL - Recognized (OL)
CE marking (see declaration of conformity): As per EU RoHS directive
LABS (PWIS) conformity: VDMA24364 Zone III
Storage temperature: -10 °C...40 °C
Degree of protection: IP00
Ambient temperature: -10 °C...40 °C
Product weight: 940 g
Type of mounting: Mounting plate, screwed on
Note on materials: RoHS compliant
Mounting position: Horizontal
Electrical connection 1, function: Power supply
Electrical connection 1, connection type: Terminal strip
Electrical connection 1, connection technology: Screw terminal
Electrical connection 1, number of pins/wires: 6
Electrical connection 1, occupied pins/wires: 6
Electrical connection 1, conductor cross section: 4 mm²
