Festo
8107588
Bus node CTEU-PB-EX1C
This Festo industrial component, part number 8107588, utilizes a Profibus DP protocol and measures 40 mm in width, 91 mm in length, and 50 mm in height with a product weight of 90 g. Designed for mounting on an electrical interface or electrical sub-base, the unit provides IP65 and IP67 degrees of protection and operates within an ambient temperature range of 0 °C to 50 °C. It features moderate corrosion stress resistance (CRC 2), VDMA24364 Zone III LABS conformity, and extensive global certifications including ATEX Zone 2/22, IEC-EX, cULus Listed, and Class I/II Div. 2 ratings alongside CE and UKCA markings. Please submit the exact part number, quantity, and application requirements to receive a formal quotation.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8107588
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8107588.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Protocol
- Probus DP
- Dimensions W x L x H
- 40 mm x 91 mm x 50 mm
- Width dimension
- 40 mm
- Type of mounting
- On electrical interface | on the electrical sub-base
- Product weight
- 90 g
- Ambient temperature
- 0 °C...50 °C
- Storage temperature
- -20 °C...70 °C
- Degree of protection
- IP65 | IP67
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364 Zone III
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- Explosion prevention and protection
- Class I, Div. 2 (CA) | Class I, Div. 2 (US) | Class II, Div. 2 (CA) | Class II, Div. 2 (US) | Zone 0 (BR) | Zone 2 (ATEX) | Zone 2 (CA) | Zone 2 (CN) | Zone 2 (IEC-EX) | Zone 2 (KR) | Zone 2 (UKEX) | Zone 2 (US) | Zone 22 (ATEX) | Zone 22 (BR) | Zone 22 (CA) | Zone 22 (CN) | Zone 22 (IEC-EX) | Zone 22 (KR)
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8107588. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
