Festo
8107589
Bus node CTEU-PN-EX1C
The Festo part number 8107589 is an industrial component supporting the PROFINET protocol with dimensions of 40 mm by 91 mm by 50 mm and a product weight of 93 g. Designed for mounting on an electrical interface or electrical sub-base, this unit operates within an ambient temperature range of 0 °C to 50 °C and features IP65 and IP67 degrees of protection. It carries a moderate corrosion resistance class of CRC 2, LABS conformity to VDMA24364 Zone III, and certifications including c UL us - Listed (OL), RCM compliance, and multiple global explosion protection ratings such as ATEX Zone 2 and Class I, Div. 2. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this component.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8107589
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8107589.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Protocol
- PROFINET
- Dimensions W x L x H
- 40 mm x 91 mm x 50 mm
- Width dimension
- 40 mm
- Type of mounting
- On electrical interface | on the electrical sub-base
- Product weight
- 93 g
- Ambient temperature
- 0 °C...50 °C
- Storage temperature
- -20 °C...70 °C
- Degree of protection
- IP65 | IP67
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364 Zone III
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- Certication
- RCM compliance mark | c UL us - Listed (OL)
- Explosion prevention and protection
- Class I, Div. 2 (CA) | Class I, Div. 2 (US) | Class II, Div. 2 (CA) | Class II, Div. 2 (US) | Zone 0 (BR) | Zone 2 (ATEX) | Zone 2 (CA) | Zone 2 (CN) | Zone 2 (IEC-EX) | Zone 2 (KR) | Zone 2 (UKEX) | Zone 2 (US) | Zone 22 (ATEX) | Zone 22 (BR) | Zone 22 (CA) | Zone 22 (CN) | Zone 22 (IEC-EX) | Zone 22 (KR)
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8107589. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
