8126915

Name: Festo 8126915 Operator unit CDSA-D3-RV
Brand: Festo

Operator unit CDSA-D3-RV

The Festo part number 8126915 is an industrial component featuring a 7-inch backlit LCD touchscreen display with a WSVGA resolution of 600x1024 pixels. Control elements comprise 20 function keys, a touch-sensitive keyboard, an enable control unit, and an emergency stop button, alongside 5 system LEDs. It operates on a DC voltage range of 19.2 V to 30 V with an input current of 5.6 A or less, and carries IP65 protection in the mounted state with the USB cover flap closed. Please submit the exact part number, quantity, and application requirements for a quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 8126915
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 8126915.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

No. of function keys: 20
Number of system LEDs: 5
Display: LCD display | With backlighting
Display properties: Touchscreen
Display size: 7"
Control elements: Touch sensitive keyboard | Enable control unit | Emergency stop button
Input current: <= 5.6 A
DC operating voltage range: 19.2 V...30 V
Display resolution: WSVGA, 600x1024 pixels
Certication: CCC | RCM compliance mark | c UL us - Listed (OL)
KC characters: KC-EMV
CE marking (see declaration of conformity): As per EU EMC directive | as per EU machinery directive | As per EU RoHS directive
UKCA marking (see declaration of conformity): To UK instructions for EMC | To UK instructions for machines | To UK RoHS instructions
Certicate issuing authority: UL E239998
LABS (PWIS) conformity: VDMA24364 Zone III
Storage temperature: -20 °C...70 °C
Relative air humidity: 5 - 95%
Degree of protection: IP65
Note on degree of protection: When USB cover ap is closed | In mounted state
Protection class: III
Ambient temperature: 0 °C...40 °C
Product weight: 950 g
Electrical power consumption: 12 W
IP address allocation: FCT

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 8126915. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
