Festo
8129114
IO-Link Master CPX-AP-A-4IOL-M12
Engineered by Festo with part number 8129114, this industrial component features IO-Link protocol integration and measures 50.1 mm in width, with overall dimensions including the interlinking block of 50.1 mm x 107.3 mm x 57.5 mm. The unit weighs 90 g, supports any mounting position via screwed-on installation, and operates within an ambient temperature range of -20 °C to 50 °C subject to IEC 61131-2:2017 derating. Built with protection class III and a low corrosion stress rating of CRC 1, it withstands designated vibration and shock resistance levels for industrial environments. Submit the exact part number, quantity, and application requirements to request a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8129114
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8129114.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Protocol
- IO-Link®
- Dimensions W x L x H
- (incl. interlinking block) | 50.1 mm x 107.3 mm x 57.5 mm
- Width dimension
- 50.1 mm
- Type of mounting
- Screwed on
- Product weight
- 90 g
- Mounting position
- Any
- Ambient temperature
- -20 °C...50 °C
- Note on ambient temperature
- Observe ambient temperature derating according to IEC 61131-2:2017
- Storage temperature
- -20 °C...70 °C
- Relative air humidity
- 5 - 95% | Non-condensating
- Nominal altitude of use above sea level
- <= 2000 m ASL (> 79.5 kPa)
- Max. installation height
- 3500 m
- Information on max. installation height
- > 2000 m ASL (< 79.5 kPa) | Observe ambient temperature derating according to IEC 61131-2:2017
- Corrosion resistance class (CRC)
- 1 - Low corrosion stress
- Vibration resistance
- Transport application test with severity level 2 as per FN 942017-4 and | EN 60068-2-6
- Note on vibration resistance
- SG1 for DIN rail | SG2 on direct mounting | Transport application test with severity level 1 as per FN 942017-4 and | EN 60068-2-6
- Shock resistance
- Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
- Note on shock resistance
- 30 g/11 ms as per EN 60068-2-27 | SG1 on DIN rail | SG2 on direct mounting | Shock test with severity level 1 as per FN 942017-5 and EN 60068-2-27
- Protection class
- III
- Contamination level
- 2
- Overvoltage category
- II
- Max. cable length
- 20 m for IO-Link® operation
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8129114. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
