Name: Festo 8161609 Soft-start valve VABF-S6-1-P5A4S1YE-G12-1T1L-PZ
Brand: Festo

Soft-start valve VABF-S6-1-P5A4S1YE-G12-1T1L-PZ

The Festo 40 mm piston gate valve (Part Number 8161609) is an electrically actuated industrial component featuring a soft sealing principle, piloted control with an internal pilot air supply port, and a non-reversible flow direction. Designed with a mechanical spring reset method, negative overlap, and a valve function for pressurization and exhaust, it supports both detenting and self-resetting manual overrides via an electrical control signal, alongside an NC contact switching element function. This unit accommodates any mounting position and withstands vibration and shock according to severity level 2 standards per EN 60068-2-6 and EN 60068-2-27, while tolerating a max. positive test pulse with 0 signal of 2000 µs and a max. negative test pulse on 1 signal of 1200 µs. Submit the exact part number, quantity, and application requirements to receive a formal quotation.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 8161609
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 8161609.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Max. positive test pulse with 0 signal: 2000 µs
Max. negative test pulse on 1 signal: 1200 µs
Width: 40 mm
Length: 155 mm
Width dimension: 41 mm
Valve size: 40 mm
Vibration resistance: Transport application test with severity level 2 as per FN 942017-4 and | EN 60068-2-6
Shock resistance: Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
Actuation type: Electrical
Sealing principle: Soft
Mounting position: Any
Manual override: Detenting | Self-resetting via electrical control signal
Structural design: Piston gate valve
Reset method: Mechanical spring
Type of control: Piloted
Pilot air supply port: Internal
Flow direction: Non-reversible
Valve function: Pressurization | Exhaust
Switching element function: NC contact
Lap: Negative overlap
Additional functions: Holding current reduction
Note on forced dynamization: Switching frequency at least once a month
Signal status display: Yellow LED, valve actuation | Green LED, pressure switch, exhausted status
Switching position sensing: Via pressure switch, exhausted status
Operating pressure: 0.3 MPa...1 MPa | 3 bar...10 bar
Pilot pressure MPa: 0.3 MPa...0.8 MPa
Pilot pressure: 3 bar...8 bar
Changeover pressure: Not adjustable
