Reference imageConfirm configuration by manufacturer part number.
Festo
8164656
Axial kit EAMM-A-X62-100A
The Festo part number 8164656 is an industrial component featuring an X62 actuator interface code and a 100A motor-in interface code with a transferable torque of 47 Nm and a maximum rotational speed of 5500 rpm. Weighing 1428 g, this RoHS-compliant unit conforms to VDMA24364-B2-L LABS (PWIS) standards and operates within an ambient temperature range of -10 °C to 60 °C, a storage temperature range of -25 °C to 60 °C, and a relative air humidity of 0 to 95% while supporting any mounting position and achieving an IP40 degree of protection. Submit the exact part number, quantity, and application requirements for a formal quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8164656
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8164656.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Mounting position
- Any
- Max. rotational speed
- 5500 rpm
- LABS (PWIS) conformity
- VDMA24364-B2-L
- Storage temperature
- -25 °C...60 °C
- Relative air humidity
- 0 - 95%
- Degree of protection
- IP40
- Ambient temperature
- -10 °C...60 °C
- Transferable torque
- 47 Nm
- Product weight
- 1428 g
- Interface code, actuator
- X62
- Interface code, motor in
- 100A
- Note on materials
- RoHS compliant
