Festo
8165400
Control unit CEPE-H8GB-128GB-C1
Manufactured by Festo, part number 8165400 is an industrial component with dimensions of 69 mm by 174 mm by 222 mm and a product weight of 1.8 kg. Designed for screwed-on mounting in a vertical position, it operates within an ambient temperature range of 0 °C to 50 °C, subject to IEC 61131-2:2018 derating, and provides an IP20 degree of protection with PELV contact protection. The unit complies with EU and UK EMC and RoHS directives, holds KC-EMV character recognition, and adheres to VDMA24364 Zone III LABS conformity with zero corrosion stress resistance. Submit the exact part number, quantity, and application requirements to request a quote for this component.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8165400
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8165400.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Dimensions W x L x H
- 69 mm x 174 mm x 222 mm
- Type of mounting
- Screwed on
- Product weight
- 1.8 kg
- Mounting position
- Vertical
- Ambient temperature
- 0 °C...50 °C
- Note on ambient temperature
- Observe ambient temperature derating according to IEC 61131-2:2018
- Storage temperature
- -20 °C...70 °C
- Relative air humidity
- 95% | Non-condensating
- Nominal altitude of use above sea level
- <= 2000 m ASL (> 79.5 kPa)
- Max. installation height
- 3000 m
- Information on max. installation height
- < 3000 m ASL (> 70 kPa)
- Degree of protection
- IP20
- Corrosion resistance class (CRC)
- 0 - No corrosion stress
- Vibration resistance
- Transport application test with severity level 1 as per FN 942017-4 and | EN 60068-2-6
- Shock resistance
- Shock test with severity level 1 as per FN 942017-5 and EN 60068-2-27
- Protection against direct and indirect contact
- PELV
- LABS (PWIS) conformity
- VDMA24364 Zone III
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- KC characters
- KC-EMV
- Certication
- RCM compliance mark
- Note on materials
- RoHS compliant
- Housing material
- Die-cast aluminum | PC | high-alloy stainless steel
- Material of screws
- Steel, nickel-plated
- IP address setting
- DHCP | Statically via web server
- Fieldbus interface, protocol
- EtherCAT
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8165400. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
