Festo
8165401
Control unit CEPE-H8GB-128GB-M1
This industrial component from Festo measures 69 mm in width, 174 mm in length, and 222 mm in height with a product weight of 1.8 kg, and features a screwed-on mounting design intended for a vertical mounting position. It operates within an ambient temperature range of 0 °C to 50 °C subject to IEC 61131-2:2018 derating, a storage temperature range of -20 °C to 70 °C, and withstands up to 95% non-condensating relative air humidity at altitudes up to 2000 m ASL. The unit provides an IP20 degree of protection, PELV protection against direct and indirect contact, VDMA24364 Zone III LABS conformity, and CRC 0 corrosion resistance, while complying with EU and UK EMC and RoHS directives alongside KC-EMV requirements. Submit the exact part number, quantity, and application requirements for a formal quote on part 8165401.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8165401
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8165401.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Dimensions W x L x H
- 69 mm x 174 mm x 222 mm
- Type of mounting
- Screwed on
- Product weight
- 1.8 kg
- Mounting position
- Vertical
- Ambient temperature
- 0 °C...50 °C
- Note on ambient temperature
- Observe ambient temperature derating according to IEC 61131-2:2018
- Storage temperature
- -20 °C...70 °C
- Relative air humidity
- 95% | Non-condensating
- Nominal altitude of use above sea level
- <= 2000 m ASL (> 79.5 kPa)
- Max. installation height
- 3000 m
- Information on max. installation height
- < 3000 m ASL (> 70 kPa)
- Degree of protection
- IP20
- Corrosion resistance class (CRC)
- 0 - No corrosion stress
- Vibration resistance
- Transport application test with severity level 1 as per FN 942017-4 and | EN 60068-2-6
- Shock resistance
- Shock test with severity level 1 as per FN 942017-5 and EN 60068-2-27
- Protection against direct and indirect contact
- PELV
- LABS (PWIS) conformity
- VDMA24364 Zone III
- CE marking (see declaration of conformity)
- As per EU EMC directive | As per EU RoHS directive
- UKCA marking (see declaration of conformity)
- To UK instructions for EMC | To UK RoHS instructions
- KC characters
- KC-EMV
- Certication
- RCM compliance mark
- Note on materials
- RoHS compliant
- Housing material
- Die-cast aluminum | PC | high-alloy stainless steel
- Material of screws
- Steel, nickel-plated
- IP address setting
- DHCP | Statically via web server
- Fieldbus interface, protocol
- EtherCAT
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8165401. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
