Name: Festo 8176326 Digital input module CPX-AP-L-16NDI-PI
Brand: Festo

Digital input module CPX-AP-L-16NDI-PI

The Festo part number 8176326 is an industrial component supporting the AP protocol and featuring dimensions of 90 mm x 106 mm x 70 mm with a product weight of 145 g. Designed for DIN rail mounting, this IP20-rated unit operates within an ambient temperature range of -20 °C to 50 °C and accommodates a maximum cable length of 30 m for inputs and 50 m for system communication. It carries CE, UKCA, and KC markings while complying with VDMA24364 Zone III LABS conformity and enduring specified vibration and shock resistance levels. Submit the exact part number, quantity, and application requirements to request a quote for this component.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 8176326
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 8176326.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Protocol: AP
Dimensions W x L x H: 90 mm x 106 mm x 70 mm
Type of mounting: With DIN rail
Product weight: 145 g
Ambient temperature: -20 °C...50 °C
Storage temperature: -40 °C...70 °C
Relative air humidity: 5 - 95% | Non-condensating
Degree of protection: IP20
Corrosion resistance class (CRC): 0 - No corrosion stress
Vibration resistance: Transport application test with severity level 1 as per FN 942017-4 and | EN 60068-2-6
Shock resistance: Shock test with severity level 1 as per FN 942017-5 and EN 60068-2-27
Contamination level: 2
Overvoltage category: II
Max. cable length: 30 m inputs | 50 m system communication
Information on max. cable length: Power supply according to nominal voltage
LABS (PWIS) conformity: VDMA24364 Zone III
Cleanroom suitability, measured according to ISO 14644-14: Statically installed element, no meaningful evaluation possible | according to ISO 14644-1
CE marking (see declaration of conformity): As per EU EMC directive | As per EU RoHS directive
UKCA marking (see declaration of conformity): To UK instructions for EMC | To UK RoHS instructions
KC characters: KC-EMV
Certication: RCM compliance mark
Note on materials: RoHS compliant | Halogen-free
Housing material: PA66 | PVC
Diagnostics via LED: Diagnostics per module | Status per channel
Diagnose per internal communication: Short circuit/overload in sensor supply

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 8176326. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
