Name: Festo 8179442 Analogue input/output CPX-AP-I-4AI4AO-U-I-M12
Brand: Festo

Analogue input/output CPX-AP-I-4AI4AO-U-I-M12

The Festo industrial component, part number 8179442, features dimensions of 30 mm by 170 mm by 35 mm and a product weight of 166 g. It supports H-rail mounting with accessories or through-hole mounting, offering an IP65 and IP67 degree of protection when unused connections are sealed. Operating within an ambient temperature range of -20 °C to 60 °C, the unit adheres to EMC and RoHS directives for both EU and UK markets alongside RCM and KC-EMV certifications. Submit the exact part number, quantity, and application requirements to request a quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 8179442
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 8179442.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Dimensions W x L x H: 30 mm x 170 mm x 35 mm
Type of mounting: On H-rail with accessories | With through-hole
Product weight: 166 g
Ambient temperature: -20 °C...60 °C
Storage temperature: -40 °C...70 °C
Relative air humidity: 5 - 95% | Non-condensating
Degree of protection: IP65 | IP67
Note on degree of protection: Unused connections sealed
Corrosion resistance class (CRC): 1 - Low corrosion stress
Vibration resistance: Transport application test with severity level 1 as per FN 942017-4 and | EN 60068-2-6
Shock resistance: Shock test with severity level 1 as per FN 942017-5 and EN 60068-2-27
Contamination level: 2
Max. cable length: 30 m outputs | 30 m inputs | 50 m system communication
Information on max. cable length: Power supply according to nominal voltage
LABS (PWIS) conformity: VDMA24364-B2-L
Cleanroom suitability, measured according to ISO 14644-14: Statically installed element, no meaningful evaluation possible | according to ISO 14644-1
CE marking (see declaration of conformity): As per EU EMC directive | As per EU RoHS directive
UKCA marking (see declaration of conformity): To UK instructions for EMC | To UK RoHS instructions
KC characters: KC-EMV
Certication: RCM compliance mark
Note on materials: RoHS compliant
Housing material: PA | PC | Die-cast zinc, nickel-plated
O-ring material: FPM
Diagnostics via LED: (Inputs-Outputs) Diagnostics per module

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Festo 8179442. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
