Reference imageConfirm configuration by manufacturer part number.
Festo
8187049
Pinch valve VZQH-2H-6-S5S5-V4V4S1PM-2
The Festo 8187049 is a manually actuated, directly controlled 2/2-way closed monostable pinch valve featuring a soft sealing principle and a nominal width DN of 6. Designed for in-line installation with DIN 32676 series A clamp fittings, this component supports a medium pressure range of 0 bar to 2 bar, a nominal fitting pressure PN of 10, and a flow rate Kv of 0.7 m³/h for compressed air and water up to 4000 mm²/s viscosity. It operates within a medium temperature range of -5 °C to 100 °C, utilizes a mechanical spring reset method, and allows mounting in any position with a reversible flow direction. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this industrial component.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8187049
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8187049.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Structural design
- Pinch valve
- Actuation type
- Manual
- Sealing principle
- Soft
- Mounting position
- Any
- Type of mounting
- In-line installation
- Fitting connection
- Clamp according to DIN 32676 series A
- Nominal width DN
- 6
- Valve function
- 2/2-way, closed, monostable
- Flow direction
- Reversible
- Medium pressure
- 0 MPa...0.2 MPa | 0 bar...2 bar | 0 psi...29 psi
- Nominal pressure of tting PN
- 10
- Burst pressure
- 1.6 MPa | 16 bar | 232 psi
- Reset method
- Mechanical spring
- Type of control
- directly
- Medium
- Compressed air as per ISO 8573-1:2010 [-:-:1] | Water
- Max. viscosity
- 4000 mm²/s
- Temperature of medium
- -5 °C...100 °C
- Ambient temperature
- -5 °C...60 °C
- Storage temperature
- 5 °C...30 °C
- Flow rate Kv
- 0.7 m³/h
- On switching time
- 1000 ms
- Switching time off
- 1000 ms
- Note on materials
- RoHS compliant
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8187049. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
