Name: Festo 8196632 Input module VAEM-XA-E-8E-N-V
Brand: Festo

Input module VAEM-XA-E-8E-N-V

Manufactured by Festo, part number 8196632 is an industrial component measuring 41.8 mm x 49.0 mm x 27.2 mm featuring 8 inputs with a 3 ms debounce time, a nominal operating voltage of 24 V DC for electronics and sensors, and support for up to 6 modules. It incorporates internal electronic fuse protection per module for short circuit input safeguarding, automatic return behavior after sensor supply overload, and power failure buffering of 10 ms. The unit operates with a typical intrinsic current consumption of 4 mA, a sensor supply voltage drop of 1 V, a maximum residual current of 0.2 A per module, and a signal 1 switching level of >= 11 V while carrying CE marking as per EU EMC and RoHS directives alongside KC-EMV certification. Submit the exact part number, quantity, and application requirements to request a quote for this component.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.

Manufacturer: Festo
Part number: 8196632
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to 8196632.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Dimensions W x L x H: 41.8 mm x 49.0 mm x 27.2 mm
Diagnose per internal communication: Short circuit/overload Power OUT PL
Max. number of modules: 6
No. of inputs: 8
Input debounce time: 3 ms
Intrinsic current consumption at nominal operating voltage for: typically 4 mA
Max. number of inputs: 8
Nominal operating voltage DC for electronics/sensors: 24 V
Power failure buﬀering: 10 ms
Switching level: Signal 1: >= 11 V
Fuse protection inputs (short circuit): Internal electronic fuse per module
Behavior after end of overload of the sensor supply: Automatic return (default)
Voltage drop of sensor supply: 1 V
Max. residual current of inputs per module: 0.2 A
Electrical isolation of inputs between channels: No
Contamination level: 2
Permissible voltage uctuations for electronics/sensors: ±25%
Permissible voltage uctuations load: ±10%
CE marking (see declaration of conformity): As per EU EMC directive | As per EU RoHS directive
KC characters: KC-EMV
Max. cable length: 30 m inputs
Vibration resistance: Transport application test with severity level 2 as per FN 942017-4 and | EN 60068-2-6
Shock resistance: Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
Corrosion resistance class (CRC): 1 - Low corrosion stress
LABS (PWIS) conformity: VDMA24364-B2-L
Storage temperature: -20 °C...70 °C
Relative air humidity: 5 - 95%
Note regarding operating voltage: SELV/PELV xed power supplies required
